01
General
12 specifications
Color Range
Tunable White
Power Consumption
250 W
LEDs
96
Pixels
1
Channels
4
LED Type
2in1
CRI
≥80
·
(Custom on request)
Dimming
16 Bit
Control
DMX RDM/ PxLNet
Input Voltage
115-277 V
Color / CCT
1800K+6000K
Optics
15°
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
L80B10 50.000
03
Operating
11 specifications
Environment
Outdoor
Storage Temperature (°C)
-40 to +90
Working Temperature (°C)
-30 to +85
Saltwater Resistant
Yes
Coastal Environmental Proof
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
5 Years
04
Physical
7 specifications
Housing Material
Aluminum (ADC12)
Cable Material
PCP
Connector Material
Nylon (PA66)
Connector Type
M20 7Pin
Cover Material
Tempered Glass
Dimensions (mm)
643 x 355 x 136
Housing Color
Grey RAL7047
