01
General
12 specifications
Color Model
Multi Color
Color / CCT
RGB
Control
SPI
Channels
126/m
·
180/m
·
78/m
Power Consumption
6.5-14.4 W/m
Input Voltage
DC (12 V)
LED Count
26/m
·
42/m
·
60/m
Pixels
26/m
·
42/m
·
60/m
LED Type
3in1
Dimming
8 Bit
Optics
120°
Pixel pitch
16 mm
02
Installation Conditions & Lighting Data
1 specification
Installation Temperature (°C)
-40 to +80
03
Operating
5 specifications
Environment
Indoor
Working Temperature (°C)
-25 to +60
IP Rating
IP20
Certificates
CE
·
RoHS
Warranty
2 Years
04
Physical
3 specifications
Cable Material
PVC
Connector Type
Bare Wire
Dimensions (LxWxH) (mm)
12 x 2.1
01
Specification Sheets & Certifications
1 file
