HS Code:
94051190
01
General
12 specifications
Color Range
Multi Color
Color / CCT
RGBW3000K
CRI
≥80
·
≥90
Control
SPI
Channels
16/m
Power Consumption
23 W/m
Input Voltage
24 V
LEDs
24/m
Pixels
4/m
Optics
15°
LED Type
4in1
Dimming
16 Bit
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
70.000 Hours L70 @ 25°C 50.000 Hours L70 @ 50°C
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
0 to +50
Working Temperature (°C)
-40 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CB
·
CE
·
FCC
·
RoHS
·
UKCA
·
UL
Warranty
5 Years
04
Physical
9 specifications
Cable configuration
Single Feed M12 connector - 300 mm
Cable entry
Direct (Single / Double feed)
Housing Material
Silicone
Cable Material
Silicone
Connector Material
Nylon (PA66)
Connector Type
Bare Wire
·
M12 3Pin
Housing Color
White RAL9003
Cover Material
Silicone
Dimensions (mm)
18 x 18
