DiGi Module P20

The DiGi Module P20 is a point-source LED solution for bold architectural façades and large-scale installations where visibility and impact are key. Designed for demanding outdoor environments, it features a wide pixel pitch ideal for dynamic patterns, motion, and expressive lighting effects. Three selectable power modes allow flexible optimization of brightness, efficiency, and run length, enabling tailored performance across each project.

↘ Adaptive Output Control — Three power modes to balance brightness, efficiency, and run length

↘ Fast, Flush Integration — Front-mount design for clean, seamless architectural installation
€ 0.00 € 0.00

  • Color Range
  • Color / CCT
  • Power Consumption
  • Power Consumption
  • Power Consumption
  • LEDs
  • Pixels
  • Channels
  • Optics
  • LED Type
  • CRI
  • Dimming
  • Lumen Maintenance Hours (h)
  • Delivered Lumen (lm)
  • Environment
  • Installation Temperature (°C)
  • Working Temperature (°C)
  • Saltwater Resistant
  • Coastal Environmental Proof
  • UV Resistant
  • Flame Resistant
  • IK Rating
  • IP Rating
  • Certificates
  • Certificates
  • Warranty
  • Housing Material
  • Cable Material
  • Connector Material
  • Connector Type
  • Cover Material
  • Dimensions (mm)
  • Control
  • Input Voltage
  • Housing Color - White
Add to cart
Contact Us

HS Code: 85395290

01
General
12 specifications
Color Range
Multi Color
Color / CCT
RGBW2700K
CRI
≥80
Control
DMX RDM/ PxLNet
Channels
32/module
Power Consumption
5 W · 10 W · 20 W
Input Voltage
48 V
LEDs
48
Pixels
8/module
Optics
100°
LED Type
4in1
Dimming
16 Bit
02
Installation Conditions & Lighting Data
3 specifications
Lumen Maintenance Hours (h)
L80B10 50.000
Delivered Lumen (lm)
1343 (RGBW3000K 20W)
Installation Temperature (°C)
-40 to +85
03
Operating
10 specifications
Environment
Outdoor
Working Temperature (°C)
-25 to +85
Saltwater Resistant
Yes
Coastal Environmental Proof
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE · RoHS
Warranty
5 Years
04
Physical
7 specifications
Housing Material
Aluminum (ADC12)
Cable Material
PCP
Connector Material
Nylon (PA66)
Connector Type
M19 5Pin
Housing Color
White
Cover Material
Tempered Glass
Dimensions (mm)
162 x 162 x 67.5
01
All Files
4 files
PDF
DiGi Module P20 Dimensions Sheet.pdf
131 KB
Download
ZIP
DiGi Module P20 Multi Color RGBW IES.zip
30 KB
Download
PDF
DiGi Module P20 Multi Color RGBW Specification Sheet.pdf
258 KB
Download
ZIP
Product drawings.zip
735 KB
Download
