01
General
9 specifications
Color Model
Single Color
Color / CCT
Single Color (Red)
CRI
≥80
·
≥90
Control
PWM
Power Consumption
13 W/m
Input Voltage
DC (24 V)
LED Count
72/m
Pixels
12/m
Optics
120°
02
Installation Conditions & Lighting Data
2 specifications
Lumen Maintenance Hours (h)
70.000 Hours L70 @ 25°C 50.000 Hours L70 @ 50°C
Installation Temperature (°C)
0 to +50
03
Operating
9 specifications
Environment
Outdoor
Working Temperature (°C)
-40 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
RoHS
·
CE
·
UL
·
UKCA
·
CB
·
FCC
Warranty
5 Years
04
Physical
9 specifications
Cable configuration
Single Feed M12 connector - 300 mm
Cable entry
Direct (Single / Double feed)
Connector Material
Nylon (PA66)
Shape
1618
Housing Material
Silicone
Cover Material
Silicone
Connector Type
Bare Wire/M12
Housing Color
White
Dimensions (LxWxH) (mm)
16 x 18
02
Photometrics (IES & LDT)
1 file
€
27.50
€
16.00
€
11.00
