01
General
7 specifications
Color Range
Tunable White
Color / CCT
2200K+5700K
CRI
≥80
·
≥90
Control
PWM
Power Consumption
14 W/m
·
17 W/m
Input Voltage
24 V
LEDs
120/m
02
Installation Conditions & Lighting Data
2 specifications
Lumen Maintenance Hours (h)
70.000 Hours L70 @ 25°C 50.000 Hours L70 @ 50°C
Installation Temperature (°C)
0 to +50
03
Operating
9 specifications
Environment
Outdoor
Working Temperature (°C)
-40 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
RoHS
·
CE
·
UL
·
UKCA
·
CB
·
FCC
Warranty
5 Years
04
Physical
8 specifications
Cable configuration
Single Feed M12 connector - 300 mm
Cable entry
Direct (Single / Double feed)
Shape
1313
Housing Material
Silicone
Connector Material
Nylon (PA66)
Connector Type
Bare Wire/M12
Housing Color
White
Cover Material
Silicone
