LTECH Mini RF remote control - P1

This compact LED controller features a V0 flame-retardant PC housing and supports 2.4GHz wireless control, removing the need for signal wiring. It delivers 1-5 channel constant voltage output for DIM, CT, RGB, RGBW, and RGBCW lighting with smooth soft-on and fade-in dimming. Compatible with MINI series RF remotes, it supports up to 10 remotes per controller and allows synchronized dynamic lighting effects across grouped devices, with built-in dynamic modes for added flexibility.

Input Signal: RF2.4GHz
Input Voltage: 12-48V
No. of Channel: 1CH
Reset Switch: Yes
Compatible RC Models:
- Mini LED Remote
  - Single-Zone: M1A/M1B
  - Multi-Zone: M1C/M1D
  - Programmable: M9
Load Current: Max. 11A
Load Power:
- 132W@12V
- 240W@24V
- 288W@36V
- 384W@48V
Working Temperature: -25°C~50°C
Dimensions: L91 × W37 × H21 (mm)
Weight: 46g
