Internal Reference:
3172292
Barcode:
3172292
HS Code:
85395210
01
General
9 specifications
Color Model
Tunable White
Color / CCT
TW (2200K-5700K)
CRI
≥80
·
≥90
Control
PWM
Power Consumption
12 W/m
Input Voltage
DC (24 V)
LED Count
120/m
LED Type
2in1
Optics
120°
02
Installation Conditions & Lighting Data
2 specifications
Lumen Maintenance Hours (h)
70.000 Hours L70 @ 25°C 50.000 Hours L70 @ 50°C
Installation Temperature (°C)
0 to +50
03
Operating
9 specifications
Environment
Outdoor
Working Temperature (°C)
-40 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CB
·
CE
·
FCC
·
RoHS
·
UKCA
·
UL
Warranty
5 Years
04
Physical
5 specifications
Connector Material
Nylon (PA66)
Housing Material
Silicone
Cable Material
Silicone
Connector Type
Bare Wire
·
M12
Dimensions (LxWxH) (mm)
15 x 7
01
Specification Sheets & Certifications
1 file
