Internal Reference:
3452501
Barcode:
3452501
HS Code:
94051190
01
General
12 specifications
Color Model
Tunable White
Color / CCT
TW (2700K-4000K)
CRI
≥80
·
(Custom on request)
Control
DMX
Channels
12/m
Power Consumption
54 W/m
Input Voltage
DC (24 V)
LED Count
24/m
Pixels
4/m
LED Type
SMD3030
Dimming
16 Bit
Optics
12°
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
L70B10 50.000
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +70
Working Temperature (°C)
-25 to +60
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CE
·
RoHS
Warranty
3 Years
04
Physical
7 specifications
Length
1000 mm
Connector Material
Nylon (PA66)
Housing Material
Aluminum (AA6063)
Cover Material
Tempered Glass
Connector Type
M17 5Pin
Housing Color
Grey RAL9023
Dimensions (LxWxH) (mm)
50 x 62
