01
General
11 specifications
Color Range
Multi Color
Color / CCT
RGBW2700K
CRI
≥80
Control
DMX
Channels
16/m
·
24/m
Power Consumption
18 W/m
LEDs
48/m
Pixels
4/m
Optics
25°
LED Type
4in1
Input Voltage
24 V
02
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +60
Working Temperature (°C)
-20 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
3 Years
03
Physical
7 specifications
Length
500 mm
Housing Material
Aluminum (AA6063)
Cable Material
PCP
Connector Material
Nylon (PA66)
Connector Type
M12 5Pin
Cover Material
Tempered Glass
Dimensions (mm)
22 x 19
