LTECH Mini RF remote control RGBW - P4

This compact LED controller features a V0 flame-retardant PC housing and supports 2.4GHz wireless control, removing the need for signal wiring. It delivers 1-5 channel constant voltage output for DIM, CT, RGB, RGBW, and RGBCW lighting with smooth soft-on and fade-in dimming. Compatible with MINI series RF remotes, it supports up to 10 remotes per controller and allows synchronized dynamic lighting effects across grouped devices, with built-in dynamic modes for added flexibility.

Input Signal: RF2.4GHz
Input Voltage: 12-48V
No. of Channel: 4CH
Reset Switch: Yes
Compatible RC Models:
- Mini LED Remote
  - Single-Zone: M1A/ M1B/ M2A/ M2B/ M4A/ M4B
  - Multi-Zone: M1C/ M1D/ M2C/ M2D/ M4C/ M4D
  - Programmable: M9
Load Current: Max. 15A
Load Power:
- 180W@12V
- 288W@24V
- 360W@36V
- 480W@48V
Working Temperature: -25°C~50°C
Dimensions: L91 × W37 × H21 (mm)
Weight: 46g

LTECH Mini RF remote control RGBW - P4

Control

Input Voltage

Input Voltage Domain

Channels

Output Voltage

Output Power Range

Curent load max

Weight

Dimensions

Package Size

Working Temperature
