01
General
12 specifications
Color Range
Multi Color
Color / CCT
RGBW2700K
CRI
≥80
·
(Custom on request)
Control
DMX RDM/ PxLNet
Power Consumption
120 W
Input Voltage
48 V
LEDs
48
Pixels
1
Optics
15°
LED Type
4in1
Dimming
16 Bit
Channels
4
02
Installation Conditions & Lighting Data
2 specifications
Lumen Maintenance Hours (h)
L80B10 50.000
Delivered Lumen (lm)
8496 (RGBW3000K 45°)
03
Operating
11 specifications
Environment
Outdoor
Storage Temperature (°C)
-40 to +90
Working Temperature (°C)
-30 to +85
Saltwater Resistant
Yes
Coastal Environmental Proof
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
5 Years
04
Physical
7 specifications
Housing Material
Aluminum (ADC12)
Cable Material
PCP
Connector Material
Nylon (PA66)
Connector Type
M20 7Pin
Housing Color
Grey RAL7047
Cover Material
Tempered Glass
Dimensions (mm)
405 x 275 x 120
