01
General
10 specifications
Color Model
White
Color / CCT
White (2200K)
CRI
≥80
Control
DMX
Channels
24/m
Power Consumption
18 W/m
Input Voltage
DC (24 V)
LED Count
48/m
Pixels
8/m
Optics
20°
02
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +60
Working Temperature (°C)
-20 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
3 Years
03
Physical
6 specifications
Length
500 mm
Connector Material
Nylon (PA66)
Housing Material
Aluminum (AA6063)
Cable Material
PCP
Connector Type
M12 5Pin
Dimensions (LxWxH) (mm)
22 x 19
