01
General
12 specifications
Color Range
Multi Color
Color / CCT
RGBW2700K
CRI
≥80
·
(Custom on request)
Control
DMX RDM/ PxLNet
Channels
16/m
Power Consumption
54 W/m
Input Voltage
48 V
LEDs
24/m
Pixels
4/m
Optics
25°
LED Type
4in1
Dimming
16 Bit
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
L70B10 50.000
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +70
Working Temperature (°C)
-25 to +60
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CE
·
RoHS
Warranty
3 Years
04
Physical
7 specifications
Length
500 mm
Housing Material
Aluminum (AA6063)
Connector Material
Nylon (PA66)
Connector Type
M17 5Pin
Housing Color
Grey RAL7047
Cover Material
Tempered Glass
Dimensions (mm)
50 x 62
