01
General
12 specifications
Color Model
Multi Color
Color / CCT
RGBW (2700K)
CRI
≥80
·
(Custom on request)
Control
DMX - RDM / PxLNet
Channels
4
Power Consumption
12 W
Input Voltage
DC (48 V)
LED Count
6
Pixels
1
LED Type
4in1
Dimming
16 Bit
Optics
15°
02
Installation Conditions & Lighting Data
2 specifications
Lumen Maintenance Hours (h)
L80B10 50.000
Delivered Lumen (lm)
404 (RGBW3000K 45°)
03
Operating
11 specifications
Environment
Outdoor
Storage Temperature (°C)
-40 to +90
Working Temperature (°C)
-30 to +85
Saltwater Resistant
Yes
Coastal Environmental Proof
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
5 Years
04
Physical
7 specifications
Connector Material
Nylon (PA66)
Housing Material
Aluminum (ADC12)
Cable Material
PCP
Cover Material
Tempered Glass
Connector Type
M16 5Pin
Housing Color
Grey RAL7047
Dimensions (LxWxH) (mm)
125 x 155
