HS Code:
85395210
01
General
9 specifications
Color Range
Multi Color
Color / CCT
RGB
CRI
≥80
·
≥90
Control
PWM
Power Consumption
18 W/m
·
24 W/m
Input Voltage
24 V
LEDs
24/m
Optics
60°
LED Type
3in1
·
4in1
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
70.000 Hours L70 @ 25°C 50.000 Hours L70 @ 50°C
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
0 to +50
Working Temperature (°C)
-40 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CB
·
CE
·
FCC
·
RoHS
·
UKCA
·
UL
Warranty
5 Years
04
Physical
9 specifications
Cable configuration
Single feed 300mm with connector
Cable entry
Bottom (Single / Double feed)
Housing Material
Silicone
Cable Material
Silicone
Connector Material
Nylon (PA66)
Connector Type
Bare Wire
·
M12 5Pin
Housing Color
White RAL9003
Cover Material
Silicone
Dimensions (mm)
18 x 18
