01
General
12 specifications
Color Range
Multi Color
Color / CCT
RGBW2700K
CRI
≥80
·
(Custom on request)
Control
DMX
Power Consumption
12 W/m
Input Voltage
24 V
LEDs
10
Pixels
1
Optics
3°x118°
LED Type
SMD3030
Dimming
16 Bit
Channels
4
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
L70B20 50.000
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +60
Working Temperature (°C)
-20 to +55
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP67
Certificates
CE
·
RoHS
Warranty
3 Years
04
Physical
7 specifications
Length
250 mm
Mounting
Wall
Housing Material
Aluminum (AA6063)
Connector Material
Nylon (PA66)
Connector Type
M12 5Pin
Housing Color
Grey RAL9023
Cover Material
Tempered Glass
€
20.00
55 in stock
€
16.00
629 in stock
€
11.00
426 in stock
€
22.00
205 in stock
![[7900162] M12 5Pin Terminator End Cap](/web/image/product.template/6024/image_512)
[7900162] M12 5Pin Terminator End Cap
€
5.50
200 in stock
