This DIN-Rail CV decoder offers PWM digital dimming without affecting LED color rendering, features a fully protective housing, and is suitable for indoor use.
• Dimming Interface: DMX512, RDM
• Input Voltage: 5~24V DC
• Output Voltage: 5~24V DC
• Output Current: 4A x 4CH Max. 16A
• Output Power: (0~20W... 96W) x 4CH Max. 384W
• Dimming Range: 0~100%, LED start at 0.1% possible
• Mounting: DIN-Rail or Screw
• Working Temperature: -30°C~55°C
• Dimensions: L112 x W35 x H67 (mm)
• Weight: 135g
