01
General
12 specifications
Color Model
White
Color / CCT
White (2700K)
CRI
≥80
·
(Custom on request)
Control
DMX - RDM / PxLNet
Channels
3/m
Input Voltage
DC (48 V)
LED Count
24/m
Pixels
1/m
LED Type
SMD3030
Dimming
16 Bit
Optics
12°
Power Consumption
54 W/m
02
Installation Conditions & Lighting Data
1 specification
Lumen Maintenance Hours (h)
L70B10 50.000
03
Operating
10 specifications
Environment
Outdoor
Storage Temperature (°C)
-30 to +70
Working Temperature (°C)
-25 to +60
Saltwater Resistant
Yes
UV Resistant
Yes
Flame Resistant
Yes
IK Rating
IK08
IP Rating
IP68
Certificates
CE
·
RoHS
Warranty
3 Years
04
Physical
7 specifications
Length
1000 mm
Connector Material
Nylon (PA66)
Housing Material
Aluminum (AA6063)
Cover Material
Tempered Glass
Connector Type
M17 5Pin
Housing Color
Grey RAL7047
Dimensions (LxWxH) (mm)
50 x 62
02
Installation Instructions
1 file
03
CAD Files
1 file
